FTTH Pigtail, a key part for FTTH systems. Short optical fiber with connectors. Connects optical equipment. Ensures high-speed data communication. Enables seamless access to broadband services like high-speed internet and HD video streaming.
Products Details
Features:
Screw-thread coupling mechanism.
Ceramic ferrules.
Low insertion loss, high return loss.
Good in repeatability and exchangeability.
100% Insertion, Return Loss, End Face and Interference inspection.
Excellent mechanical endurance.
High credibility and stability.
Complying with Telcordia ,GR-326-Core, IEC and RoHS Standard.
Parameters:
| Product | FTTH Pigtail | Certification | RoHS,CE IS09001 |
| Fiber mold | SM/MM | Fiber Count | 1-12 Cores |
| Fiber Type | G657A1 / G652D.... | Color | Black,White or Custom |
| Connector | SC/APC | Length | 20m / 30m / 50m Customized |
| Outer Jacket | PVC / LSZH / OFNP / PE | Sheath Material | PVC/LSZH |
| Insertion Loss (dB) | ≤0.3 | Return Loss (dB) | ≥60 |
| Interchangeability (dB) | ≤0.2 | Tensil Strength (N) | ≥1000 |
| Operating Temperature(℃) | -20~+85 | Storage Temperature (C) | -40~+85 |
| Packaging | 44*44*50 | Production Capacity | 20000 PCS/Day |
| *Contact us for further information | |||
Applications:
CATV, and Multimedia
Telecommunication networks
Active device interface
Telecommunication networks
Gigabit Ethernet
Data processing networks
Interconnection for O/E modules
Premise installations
Optical switch interframe connection
Asynchronous Transmission Mode (ATM)
Ordering Information
Order Information
| Fiber Cable Type | 0.25mm bare fiber / 0.6mm,0.9mm tight buffer / 0.6mm, 0.9mm easy-strip 0.6mm,0.9mm semi-tight buffer / OEM ODM customized |
| Connector | SC/ LC / ST / FC |
| Fiber Mode | G.652.D / G657A1 / G657A2 / OM1 / OM2 / OM3 / OM4 / OM5 |
| Jacket Color | White / Black / Customized |
| Jacket Material | PVC / LSZH / Hyterl |
| *ALL Types can be customized according to the customer's requirements | |
