Fireproof 2/4/8/12/24/48/96/144 Fiber Optical G657A2 G657B3 Distribution Indoor Cable LSZH Yellow Sheath
Fiber optic distribution cable is designed to distribute optical signals from a central location to multiple endpoints. It consists of several optical fibers surrounded by a protective sheath.
The fiber optic distribution cable offers several advantages. Firstly, it provides extremely high bandwidth and data transmission speeds, enabling the transfer of large amounts of information in a short time. Secondly, it is immune to electromagnetic interference, ensuring reliable and stable signal transmission even in environments with high electrical noise
Feature
- Flexible, flame-retardant & color coded outer jacket
- Non-unitized designs provide space savings and cost advantages
- Work as pigtails and patch cords
- Optical communication cables for inside plant installations
- Suitable for indoor use communication equipment
Applications
1. Indoor cabling and distribution
2. Interconnection of fiber optic equipments, especially ODF
3. Used in patch cords and pigtails
Printing at outerjacket of optical cable
White color printing words at each meter distance,standard printing content as following ,also can match the
customer require for the printing content.
1.Meter mark.
2.Style of optical cable and fiber account.
3.Manufacturer name.
4.Manufacture date.
Products Details
- Technical Parameters
- Fiber Optic Cable Options
- Fiber Optic Cable Jacket &Diameter Options
- Fiber Optic Cable Core Type Options
| Cable Count | Outside Diameter | Tight buffer Diameter |
Weight | Minimum allowable Tensile Strength (N) | minimum allowable Crush Load （N/100mm) | Minimum Bending Radius (MM) | Storage temperature | |||
| （MM) | （MM) | （KG) | short term | long term | short term | long term | short term | long term | ( ℃) | |
| 04 | 5.0 | 0.9 | 22.00 | 600 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
| 06 | 5.0 | 0.9 | 23.00 | 600 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
| 08 | 5.5 | 0.9 | 28.00 | 600 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
| 12 | 6.0 | 0.9 | 38.00 | 600 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
| 16 | 7.2 | 0.9 | 42.00 | 600 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
| 24 | 8.3 | 0.9 | 58.00 | 600 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
| 48 | 10.0 | 0.9 | 96.00 | 600 | 200 | 1000 | 200 | 20D | 10D | -40+60 |
