Rely on our MPO MTP Trunk Cable for high-density data center connectivity. This cable is precision-engineered to support 100G applications with exceptional performance. It features US Conec MTP and Senko MPO Plus connectors, ensuring low insertion loss and high return loss for reliable signal integrity. Factory-terminated and tested for quality, this cable is ready for high-performance networking, providing a seamless solution for your data transfer needs.
Products Details
Feature:
USCONEC; SENKO; NISSIN; SUNCALL; Chinese brand
Different MT inserts available (Base-8, Base-12,Base-16, Base-24)
Color-Coded Connector Boots for Easy Identification
Corning ClearCurve® YOFC Fiber with 7.5mm Min. Bend Radius
Available OFNR、OFNP、CPR(B1ca/B2ca/Cca/Dca/Eca)
Available in single sheath (2.0mm to 3.0mm, typically overall length ≤15m) and double sheath (4.5mm to 5.5mm)
RoHS2 Certification
Technical Parameters:
| Connector A | MTP® Female (Pinless) | Connector B | MPO Female (Pinless) |
| Polish Type | UPC to UPC | Glass Fiber | Corning Clear Curve® |
| Fiber Mode | OM4 MMF 50/125μm | Wavelength | 850/1300nm |
| Fiber Count | 8 Fibers | Polarity | Type B |
| Cable Outside Diameter(OD) | 3.0mm-17.3mm | Cable Jacket | Plenum(OFNP) |
| Min.Bend Radius(Optical Fiber) | 7.5mm | Min.Bend Radius (Fiber Cable) | 20/10D(Dynamic/Static) |
| Connector Durablity | 500 times | Tensile Strength(Long/ShortTerm) | 80/240N |
| Insertion Loss | 0.35dB Max(0.15dB Typ.) | Return Loss | ≥20dB |
| Attenuation at 850nm | ≤2.3dB/km | Attenuation at 1300nm | ≤0.6dB/km |
| Operating Temperature | -10 to 70℃(14 to 158F) | Storage Temperature | -40 to 85℃ |
| Glass Fiber | Corning, YOFC | Operating Temperature | -10 to +70°C |
Applications:
HPC(High-Performance Computing)
Datacom
DC(Data Center)& Hyperscale DC
LAN and SAN Backbone Network
10G to 10G inter-connect/40G to 40G inter-connect/100G to 100G inter-connect of Base-12 or Base-24
800G QSFP-DD/OSFP DR8 and 800G OSFP XDR8 of Base-16
Ordering Information
FIBER CABLE OPTIONS
| Applied Environment | Indoor/Outdoor | |||
| Fiber Cable Type | Mini cable / Loose tube cable / Distribution cable / Armored loose tube cable | |||
| Outer Diameter(OD) | 2.0mm / 3.0mm / 4.2mm / 5.0mm / 6.0mm / 8.5mm / 10.0mm / 12.5mm / Customized | |||
| Fiber Count(F) | 8F / 12F / 16F / 24F / 36F / 48F / 72F / 96F / 144F / 288F/ Customized | |||
| Fiber Mode | SM: | G652D/ G675A1/ G657A2/ G657B3 | MM: | OM1/ OM2/ OM3/ OM4/ OM5 |
| Jacket Color | Yellow / Lime Green / Aqua / Black / Erika Violet / Customized | |||
| Jacket Material | PVC / LSZH / TPU / PE / HDPE | |||
| Fire Rating | OFNR OPNP B1ca B2ca | Cca Dca Eca_ Fca | ||
CONNECTOR OPTIONS
| Connector Type (End A&End B) | MTP/MPO Base8/ MTP/MPO Base12/ MTP/MPO Base16/ MTP/ MPO Base24 / Customized |
| Connector Brand | USCONEC / SENKO / NISSIN / SUNCALL / Made in China |
| Connector Mode | Male (Pinned) / Female( Pinless) |
| Physical Contact | (EndA) Flat PC—APC(8°) / (EndB) Flat PC —APC(8°) |
| Optical Performance | Premium / Elite / Low Loss / Standard Loss |
| Breakout Length(mm)* | 300 / 500 / Customized |
| Pulling | NA / With Mesh / With Corrugated Pipe |
| *Please work with our engineering team for more details | |
Polarity
| End A | Type A | Type B | Type C |
| End B | Type A | Type B | Type C |
| Please work with our engineering team for more details | |||
Length Wizard
| Unit(M/Feet) | 3 / 5 / 10 / 20 / 60 / 80 / 100 / 120 / (M) / Customized |
| *Please work with our engineering team for more details | |
