SC/UPC Ftth fiber optical Fast Connector
SC/UPC Fast Connector is a fiber optic connector with SC interface and UPC polishing. It’s for single-mode fiber, enabling fast connection. Used in optical communication and network equipment. Low loss and convenient.
Features
Precise mechanical dimensions
Ceramic core APC, UPC grinding
Low insertion loss, high return loss
Comply standard of IEC61754-4
Adopt standard metal parts.
ROHS compliant
Applications
Connections at the desk for LAN environments
Patch panels
Direct equipment termination
Fiber to the Subscriber (FTTH) applications
Repair/replacement requirements
Equipment test leads
Products Details
- Technical Parameters
- Order Information
| Product name | Fast connector |
| Fiber mode | Single mode / Multi mode |
| Insertion Loss(dB) | ≤0.30db |
| Return Loss(dB) | ≥60 |
| Operating Temperatures℃ | -40~+85 degree |
| Color | Blue |
| wavelength | 1310/1550nm |
| Length | 50mm / 60mm |
| Certification | CE/ROHS/ISO9001/ANATEL |
| Packaging Details | Packed in cartons or as per customer request |
| Selling Units | Single item |
| Single package size | 5.5X0.7X0.7 cm |
| Single gross weight | 0.250 kg |
| Minimum Order Quantity | 1000 |
| Delivery Time | 5-8 work days |
| Supply Ability | 10000pcs per week |
| Payment Terms | L/C, T/T |
